您当前的位置:首页 / 产品中心 / 热水设备 / 芯片加热热水机组-商务宾馆专用
市场售价：75800
详细介绍：
High Bfficloncy heat storage modulo type heat supply unit
SST-EF method high efficiency heat storage module type heating unit can be a one-time storage 2-4 tons of high temperature hot water, you can use the valley period of heating, peak period of downtime mode, a machine can provide 40 rooms of the hotel hot water. Equipment built-in dual control system,mutual reserve,to ensure that 365 days a year does not stop.
Designed for high-end hotels
高效蓄热模块式电锅炉
SST-EF意法高效蓄热模块式供热机组一次性可蓄2-4吨高温热水，可以使用谷时段加热，峰时段停机的模式，一台机器可提供宾馆40个房间热水。设备内置双控系统，互为备用，保证一年365天不停机。
专为高档宾馆而设计
Technical parameters/技术参数
| Product model 产品型号 | XP2000-4 | XP2000-6 | XP2000-8 |
| Hot water capacity (L) 热水容量(L) | 2000 | 3000 | 4000 |
| Rated power (Kw) 额定功率(Kw) | 26 | 30 | 39 |
| working voltage (V) 工作电压(V) | 380 | 380 | 380 |
| Switching capacity (A) 开关容量(A) | 70 | 90 | 120 |
| Pipe diameter (mm) 水管直径(mm) | 40 | 40 | 40 |
| Total power cord cross-sectional area(mm²) 电源线截面积(mm²) | 4*10三相四线 | 4*16三相四线 | 4*16三相四线 |
| Thermal efficiency (%) 热效率(％) | 98.9 | 98.9 | 98.9 |
| Equipment size (mm) 设备尺寸(mm) | 1140*940*1700 | 2280*940*1700 | 3420*940*1700 |
| Air machine net weight (Kg) 空机净重(Kg) | 200 | 260 | 320 |
